Cinebot Max with crew in Las Vegas

Cinebot Max model features and limits below are based on MRMC manufacturer specifications. Options, installed configuration, payload and available performance must be confirmed with our team for your shoot.

  • Ergonomic, Practical & Portable: The Cinebot Max boasts a lightweight, slim design, making it effortless to pack and transport. This allows you to put creative motion control cameras on set both in studio and location.

  • Manual Camera Control: Users can easily adjust and record camera positions or keyframes, allowing for precise control over movements.

  • Battery Operated: With a battery option that lasts up to 10 hours, the Cinebot Max provides extended operation without the need for a main power source.

  • Smartphone Input: Movements can be recorded or input directly from a mobile device, offering flexibility and convenience in controlling the robot. Our team can use these moves as a starting point for production planning.

  • User-Friendly Interface: Designed with simplicity in mind, the system ensures easy control for creatives and directors, maximizing efficiency on set. Contact us to confirm the crew and setup for your production.

Cinebot Max robotic arm holding a cinema camera against a turquoise branded background
Cinebot Vegas robotic camera arm and pedestal against a turquoise branded background

CINEBOT MAX KEY SPECIFICATIONS

  • Camera Payload: Supports up to 44lb (20kg), allowing for a wide range of professional and cinema cameras.

  • Reach: Offers a maximum reach of approximately 5’ 9” (1.75m), providing flexibility to capture shots from various angles. The reach is how far from the centre the camera can be.

  • Height: The Cinebot Max achieves a maximum height of 10’ 6” (3.2m). This, combined with the long reach, gives a huge range of motion in space. Add the track and the opportunities are almost limitless.

  • Track and Pedestal Options: The model is offered in a pedestal configuration for convenient wheel-in access on set, or on track for versatile 7-axis motion.

OPERATING ENVELOPE

MAX HEIGHT ON TRACK (FROM GROUND)

3.2m / 10.5ft

LOWEST POSITION

0m / 0ft

MAX REACH (FROM ROTATE CENTER)

1.75m / 5.7ft

CINEBOT RIG PERFORMANCE

ARM ARC MOVE

3.6 m/s maximum speed at camera

BASE ROTATION

+/- 360˚ 120˚/s

PAN

+/- 360˚ 210˚/s

TRACK

2 m/s; 1.8 m track sections

ELBOW

+/- 360˚ 150˚/s

ROLL

+/- 360˚ 210˚/s

ARM COMBINED WITH TRACK

5.6 m/s maximum speed at camera

SHOULDER LIFT

+/- 360˚ 120˚/s

TILT

+/- 360˚ 210˚/s

TRACK & RISER SPECIFICATIONS

TRACK WIDTH

24" in (61 cm) Wide

TRACK WEIGHT (1.8M LENGTH)

27kg / 59lbs

STANDARD RISER

20cm / 7.9 in

TRACK WIDTH (WITH RISER)

45.5" in (116 cm) Wide

WEIGHTS

CINEBOT MAX ARM WEIGHT

66kg / 145lbs

MAXIMUM CAMERA PAYLOAD

20kg / 44lbs

CINEBOT MAX BASE WEIGHT

47kg / 104lbs

POWER

POWER REQUIREMENTS

110 - 240 VAC
